Product Number: VCS650-2W-50-EN
2-Way ceiling speaker with fire dome for voice alarm applications certified EN 54-24, suitable for voice announcements and background music with excellent sound quality in buildings. The 50W powered speaker is equipped with a 165mm 2-way system featuring a
high-quality tweeter and a 100V transformer with 4 power adjustments. Low impedance operation is also possible.
2-Way ceiling speaker with fire dome for voice alarm applications certified EN 54-24, suitable for voice announcements and background music with excellent sound quality in buildings. The 50W powered speaker is equipped with a 165mm 2-way system featuring a
high-quality tweeter and a 100V transformer with 4 power adjustments. Low impedance operation is also possible.
The sturdy metal housing in RAL 9016 guarantees long-term durability.
Thanks to an innovative magnetic fastening, the finely perforated speaker grille can quickly be removed or replaced by a grille of a different color, even after the installation.
The speaker is impregnated against dampness. Protection class IP 21C secures the speaker against the risks of environmental influences.
Fast and easy installation via a screw mounting system.
• 2-way system
• thermal fuse
• magnetic fastening of grille
| Feature | Description |
| Power | 50/25/12,5/6,25/ (8) W |
| Impedance (100V) | 200/400/800/1600/ ohm |
| Frequency Range | 65 – 24.000 Hz |
| Frequency Response | 80 – 22.200 Hz |
| SPL 1W/1m, peak | 94,1 dB |
| SPL , 1W/4m, peak | 82,1 dB |
| SPL Pmax/4m, peak | 99,0 dB |
| SPL, rated noise power / 4m | 94,3 dB |
| Sensitivity EN54-24, 1W/4m | 77,5 dB |
| Sensitivity EN54-24, 1W/1m | 89,5 dB |
| Dispersion -6dB, 500Hz | 180° |
| Dispersion -6dB, 1KHz | 180° |
| Dispersion -6dB, 2KHz | 140° |
| Dispersion -6dB, 4KHz | 56° |
| Feature | Description |
| Dimensions | 264 x 240 mm |
| IP Rating | IP21 |
| Weight (net) | 3,75 kg |
| Ceiling Cut-out | 238 mm |
| Temperature range | -10 / +55 C° |
| Mounting | Screw system |
| Connector | 5-pin screw terminal |
| Maximum cable cross section | 4,9mm² |
| Max. cable cross section loop | 2×4,9mm² |
| Colour | RAL 9016 |
| Part No. | Description |
| VCS650-2W-50-EN | 6.5” 2-Way 50W Ceiling speaker,RAL 9016,Metal, Firedome, certified EN 54- 24 |
